API 5CT 5-1/2 P110 Ltc casing coupling
-
API 5CT 5-1/2 N80 btc casing coupling -
API 5CT 5-1/2 N80 stc casing coupling -
API 5CT 5-1/2 N80 Ltc casing coupling -
API 5CT 5-1/2 P110 btc casing coupling -
API 5CT 5-1/2 P110 stc casing coupling -
API 5CT 5-1/2 K55 btc casing coupling -
API 5CT 5-1/2 K55 ltc casing coupling -
API 5CT 5-1/2 K55 stc casing coupling
Application: casing coupling is a kind of drilling tool in oil field, which is mainly used for casing connection. The casing coupling mainly solves the problem that the existing coupling is prone to fatigue fracture due to stress concentration.
Structure:The casing end is connected with the inner wall of the coupling by tapered thread, and the end of the coupling body is connected with the oil pipe by the same thread and the same pitch flat thread. The utility model has the characteristics of relieving the stress concentration at the root of the external thread of the single taper thread connecting sleeve, not easy to produce fatigue fracture, and the connection effect is good.
The thread type of casing couplngs main include: Long Round-thread Casing Coupling(LC), Short Round-thread Casing coupling(SC), Buttress Thread Casing Coupling(BC), and steel grade mainly include: J55, K55, N80, L80, P110 and so on.
Place of Origin:
Brand Name:
Model Number:
Material:
Technics:
Shape:
Product name:
Head Code:
ROUND
Color:
WHITE
Surface treatment:
Usage:
